Vertical Form-Fill-Seal machine for Liquids

Vertical Form-Fill-Seal machine for Liquids

  • Category
    Pouch Making Filling Machine
  • Model
    EZP-F800
  • 4-Lanes, Fully Automatic, Stainless Steel high-performance vertical form-fill-seal machine (VFFS), designed specifically for the handling of fluids, liquid products packed in heat sealable materials of rollstock film. The special forming tube shape and ensure less air into the final bag, providing extra freshness and a longer product shelf-life. Photo sensors for an automatic alignment of the film to ensure a correct vertical sealing, reducing the waste of material and reprocessing for vertical seal open. Language Panel Control: English, Chinese. All operational parameters such as draw-down length, sealing time and speed are programmable. Visualization of the main machine operations process: sealing temperature (rea / set), production speed, opening of the traction belts, alarms, bags counting and the selection of the main functions like manual operation, test mode, settings of the time and parameters.

  • Model

    EZP-F800
  • Packaging material

    OPP/CPP、OPP/CE、MST/PE、PET/PE
  • Sealing method

    Back seal、Rounded cut
  • Film width

    160-280mm
  • Bag width

    17-30 mm
  • Bag length

    50-150mm
  • 1 Lane Packing speed

    20-30 bags/min/lane
  • Air requests

    8kg/cm2 600L/min
  • Power supply

    AC 220V, 1 ph , 60 HZ, 3.5 KW
  • Weight

    300 kgs
  • Machine Dimension

    1440 (L) x 1217 (W) x 1690 (H) mm
  • Filling type

    Servo-driven
